安装水泵防震基座
Installation of pump base
为降低水泵台面振幅，有限控制水泵振动对管道的传递，在水泵安装弹簧隔振器或橡胶隔振器时，水泵基座下面必须加装惯性台座，增加质量配重，提高隔振器使用稳定性。惯性基座重量*般为水泵重量的1.5~3倍。基座框架由槽钢焊接而成，内浇灌水泥，并配置双向150×150钢筋。基座长宽尺寸，*般为水泵底座尺寸基础上，长度方向各留边200mm，宽度方向各留边100mm。
In order to reduce the amplitude of mesa of pump, finite control pump vibration of pipeline transfer,in the pump installed spring vibration isolator or rubber vibration isolator, below the water pump base must be equipped with inertial pedestal, increase weight, improve isolator using stability.1.5~3times the weight of the inertia base of the pump. The base frame is welded by steel, cement and water inside, 150 * 150 reinforced two-way configuration. Base length and width size, generally based on the
size of the pump base, the length of the direction of the left side of the 200mm, the width of the
direction of the left side 100mm.
上海淞江减震器集团有限公司可根据客户提*的水泵图纸，免费深化设计水泵惯性基座CAD图纸，并提*客制化的惯性基座产品。
Shanghai Songjiang shock absorber manufacturing Co., Ltd. can according to customer drawings of the pump,free of charge to deepen pump inertia base CAD drawings, and provide customized inertial base products.
水泵振动控制治理效果
Treatment effect of water pump vibration control
基于水泵采用的隔振方式，安装弹簧隔振器的隔振效果可达到95~99%以上，安装橡胶隔振器的隔振效果可达到80%以上，从而从根本上解决水泵振动带给人们生活及工业生产上的困扰。
Based on the vibration isolation method of water pump, the vibration isolation effect of the spring isolator can reach 95~99%, and the vibration isolation effect of the rubber isolator can reach more than 80%.
