减震器样本VIEWS

P44,侧面托浮式减震方式

来源:P44,侧面托浮式减震方式 发布于:2015-12-07 08:48   浏览:381

上海淞江减震器集团有限公司生产各种弹簧减震器产品,注册增加5910万人民币,以下是淞江集团电子样本P44页对水泵减震器安装形式的.二种介绍:侧面托浮式减震方式!

P44,侧面托浮式减震方式,淞江集团电子样本

二、侧面托浮式减震方式   The vibration mode of the side support
1、概述:水泵安装于混合型惯性基座上部,惯性基座重量*般为水泵重量的1.5~2倍左右。基座长度方向两侧设有旁托支架,选用ZFT型、JB型或JL型弹簧隔振器,基座底面与地面间距*般为50mm左右。此种隔振形式使设备重心下降,配重大,台面振幅小,隔振设备稳定性好(现在工程上也是常用的*种设计、使用方式)。减振弹簧的设计制造采用大直径、大中径、高径比小的弹簧,具有应力小、抗疲劳强度高、使用寿命长等优点。
1, overview: the pump is installed on the upper part of the mixed type of inertia, the inertia of thebase weight of the pump is generally about 1.5~2 times. BaseIn the direction of the length, the ZFT -
type, JB - type, JL - type spring vibration isolator is used, and the bottom surface of the base and the ground space are generallyAround 50mm. This kind of vibration isolation mode makes the equipment'
s center of gravity down, with a big table, the table is small, and the stability of the vibrationisolation device is good.Process is also commonly used in a design, the use of the way.The design and
manufacture of vibration damping spring is made of large diameter, large diameter, high diameter ratio of small spring, with small stress, high anti fatigue strength, useLong life, etc..

以上信息来源于上海淞江减震器集团有限公司上海弹簧减震器官方网站,如需了解更多产品信息可以登录:http://www.songjiangjituan.com查询,我们是上海实体工厂欢迎新老客户到我厂实地参观考察!
工厂地址:上海市嘉定区曹胜路699号,电话:021-33666667
